PN5180 Module / NFC Module / ISO15693 RFID IC High Frequency ICODE2 Read and Write Module

Description

What is the PN5180 Module? The PN5180 / NFC Module / ISO15693 RFID IC High Frequency ICODE2 is a device for reading and writing high-frequency RFID tags. It supports the ISO15693 standard and ICODE2 IC tags. Features Support ISO15693 Standard Support ICODE2 IC High-Frequency Operation Read and Write RFID/NFC Compatible with Arduino Use Cases This module can be used to create radio frequency identification systems, such as keyless access systems that unlock doors or activate other devices when specific RFID tags are detected. Tutorial: How to use PN5180 NFC/RFID The PN5180 is a high-level device for reading and writing ISO15693 and ICODE2 IC RFID tags. Ideal for projects requiring contactless interaction. What You Need Arduino or compatible microcontroller USB cable RFID tag Steps Connect the PN5180 module to your Arduino’s digital pins (refer to the datasheet for details) Download and install the MFRC522 library Load an example sketch that reads RFID tags Configure the PN5180 module for external antenna if necessary (check the datasheet) Verify communication between Arduino and the module using the serial console Test with various types of RFID tags Program custom features such as alarms or counters based on RFID events Sample Code // Include MFRC522 library #include // Define PN5180 module connection pins #define SS_PIN 10 #define RST_PIN 9 void setup() { Serial.begin(9600); MFRC522 mfrc522(SS_PIN, RST_PIN); // Initialize the PN5180 module } void loop() { if (mfrc522.PICC_IsNewCardPresent()) { // Read RFID tag data and print to serial } } Mini Project Create a keyless access system that unlocks a door when a specific RFID tag is approached Common Errors Library installation issues Incorrect pin connections Tag recognition problems Recommended Accessories ISO15693 RFID tags External antenna for PN5180 module Arduino Uno R3 MFRC522 library Frequently Asked Questions Does the PN5180 work with microcontrollers other than Arduino? Yes, as long as your microcontroller pins are compatible and you download the appropriate library. How can I improve the read range of the PN5180 module? Use an external antenna or properly position the internal antenna of the module.
