Brushless DC Cooling Fan 12V 0.1-0.3A 50x15mm 5015S

Description

Brushless DC cooling fan 12V 0.1-0.3A 50x15mm 5015S
– Specifications: – Mid-speed brushless blower ultra-quiet – Dimensions: 50mm (diameter) x 15mm (H) – Blade material: UL94V-0 PBT thermoplastic – Housing material: PBT thermoplastic – Operating temperature: -10°C to +60°C – Expected life at 40°C: 40,000 hours – DC 12V / 0.1-0.3A – Silent design with sealed bearing
Technical datasheets for all components are available upon request. Please contact us via the contact form if not included in the product download. Tutorial: How to use 5015S Fan
The 5015S fan is ideal for cooling electronic components in 3D printers and CNC machines. Suitable for beginners and intermediates.
What do you need
– 12V power supply
– 2.5mm connector
– Connection cable
Steps:
1. Ensure the power supply is 12V.
2. Prepare the 2.5mm connector.
3. Connect the connector to the cable.
4. Attach the cable to the power supply.
5. Connect the other end of the connector to the fan.
6. Check the maximum current on the datasheet.
7. Turn on the power supply and verify operation.
8. Check that the fan is rotating correctly.
Mini-project
Mount the fan on a 3D printer to improve cooling of electronic components.
Common errors
– Connecting to a voltage other than 12V
– Using an incompatible connector
– Not verifying the maximum current
– Not checking operation before use
Recommended accessories
– 12V power supply
– 2.5mm connector
– Connection cable
– Soldering tools
Frequently asked questions
– Can I use a different voltage power supply? Check the maximum allowed voltage on the datasheet.
– What connectors are compatible? Check the supported connectors on the datasheet.
– How can I check if the fan is working correctly? Turn on the power supply and verify that the fan is rotating.
– Can I use this fan for 3D printers and CNC machines? Yes, it is designed for these applications.
